Blood bag traceability management

Blood Bag Traceability Management

Improved operational accuracy

Enhanced workflow efficiency

Real-time visibility into blood bag movement across the supply chain

Contact Us

Challenges

There are concerns about whether donor data and blood bag data can be accurately linked

Shipping operations are labor-intensive and time-consuming

IT infrastructure is not fully developed, it is difficult to automatically record transport information

arrow

PJM RFID to manage blood bag tracing

At the blood donation venue, donor information is identified using wristbands issued on-site with barcodes or QR codes.

A PJM RFID label is then issued and applied to each blood donation bag, securely linking the donor ID with the bag ID.

The bags are then placed into a transport container, and shipment preparation is completed simply by batch-scanning them with a tunnel reader.

This significantly improves both the accuracy and the speed of the operation.

PJM RFID to manage blood bag tracing

Benefits

What is PJM RFID?

PJM (Phase Jitter Modulation) RFID is a high-speed, high-precision RFID technology compliant with ISO 18000-3 Mode 2.

  • Up to 600 tags read per second
  • Stable reading performance even in metallic, water, and stacked conditions
  • Scanning is possible without worrying about tag orientation (3D reading)
  • Label material for radiation sterilization
  • Operates in cryogenic conditions:
    • C-chip series: down to –40°C
    • D-chip series: down to –80°C
  • NFC-enabled and readable with smartphones
  • Supports ISBT 128-compliant data recording

Positive donor identification for blood safety

Donors are identified using wristbands printed with barcodes or QR codes. Clear identification at the time of blood collection prevents mix-ups and supports safe and reliable blood management.

Accurate blood bag identification for end-to-end traceability

A PJM RFID label is issued and applied to each blood donation bag, securely linking the scanned donor ID with the bag ID. This single label enables consistent, end-to-end tracking from the donor site to the blood center, significantly enhancing traceability.

Efficient and accurate dispatch with full traceability

Blood donation bags are consolidated into a transport container and batch-scanned using a tunnel reader. All bags can be read quickly and accurately, regardless of label orientation or positioning.
In addition, a PJM RFID temperature logger automatically records container temperature during transport, enabling integrated temperature monitoring, safety management, and record keeping.
